i just got a Honda 3 wheeler. I just needed something to get me into some new areas to set up deer blinds, and feeders. in order to hunt some areas where i cannot get a truck in to load up my Deer and Wild Hogs in the woods.

i am not sure what year or model it is, i am assuming it is a 1981 - 1983 ATC 200 .. or maybe a 185 . if anyone has any opinion on its year and model, please let me know.

PICTURES POSTED HERE ---> http://s185.photobucket.com/albums/x29/Jimraby/

PICTURES


the guy i got it from, just cleaned the Carb, cleaned Gas tank and put a new spark plug in it. what else should be done??
i have read that it takes 1.5 quarts of oil, but what oil is best?
is there a Oil filer, and where?

air filter location?
Fuel Filter?

it usually starts right up w/ 1 or 2 pulls.. but sometimes it also seems to take forever untill my arm hurts before it starts.
what can be done to help it start right up everytime?

i am a decent car mechanic, but im almost clueless when it comes to these small, pull start engines.



Great pics.
as far as an oil filter it does not have a filter but a screen that can and should be cleaned when doing the oil change, behind the 24mm screw plug.

It does look like a older 200atc I have bought a 83 model for my wife and they seem to go and go, the pull rope broke once.
We had a problem where it would not start if pulling the rope slow but when pulling the rope fast it had more spark, found out it was a bad plug.
so keep a spare plug in the tool case.

what are the motor number or frame numbers?
also a clymer manual number M326 should cover any repairs or maintenance it may need
